Research vehicles


Land Rover Range Rover Evoque

Vehicle with dynamic tire pressure control, semi-active chassis and decoupled brake system with continuous wheel slip control for driving dynamics studies

Power: 110 kW / 150 hp, Torque: 380 Nm, vmax.: 182 km/h, Empty weight: 2275 kg, Tire size: 235/55 R19, Cw-value: 0,35

Land Rover Range Rover EvoqueTU Ilmenau

Ford Focus RS

Vehicle for the investigation of new types of temperature sensors and vehicle dynamics studies

Max. Power: 257 kW / 350 hp, Max. Torque: 470 Nm, vmax.: 266 km/h, 0-100 km/h: 4.7 s, Empty weight: 1529 kg, Drive: 2.3 l EcoBoost petrol engine, TwinScroll turbocharger, RS-Dynamic Torque Vectoring


Ford Focus RSTU Ilmenau

Audi A5 Sportback

Human-machine interaction (e.g. investigation of pedal feel characteristics) Brake-by-wire B8 series

Petrol engine, displacement: 1984 cm³, Rated power: 155 kW / 210 hp, Maximum torque: 350 Nm, Acceleration, 0-100 km/h: 6.4-7.9 s, Tare weight: 1590 kg, vmax: 241 km/h

Audi A5 SportbackTu Ilmenau

Opel Ampera

Vehicle with range extender for the investigation of drive concepts

Max. Power: 111 kW / 150 hp, Max. torque: 370 Nm, vmax: 161 km/h, 0-100 km/h: < 10 s, empty weight: 1732 kg, E-drive: 54 kW generator, 16 kWh battery, 40-80 km range, Range extender: 4 cylinder petrol engine 1398 cm³, 63 kW / 86 hp at 4800 rpm >400 km range

Opel AmperaTU Ilmenau

Mitsubishi i-MiEV

Vehicle with electric drive for the investigation of drive concepts

Inspection HMI, Power: 49 kW / 67 hp, 0-100 km/h: 15,9 s, vmax: 130 km/h, Capacity: 16 kWh, Range: 150 km, Empty weight: 1110 kg, Tire measuring trailer

Mitsubishi i-MiEVTU Ilmenau

Tyre measurement trailer

A single-axle tire measurement trailer has been developed by the Automotive Engineering department to analyze the frictional behavior of tires on dry and wet roads:

Definite adjustment options for wheel position variables, Large variation of different wheel loads, Highly dynamic tire inflation pressure system allows control of the internal tire pressure, Electric servo-hydraulic brake system for realizing brake slip, Measurement data acquisition and control software for controlling the brake system is realized using LabVIEW Realtime (CompactRIO real-time system), Wheel force sensor Kistler RoadDyn S635 allows precise and highly dynamic recording of forces and moments

ReifenmessanhängerTU Ilmenau

Segway i2 / Segway x2 (off-road )

Investigation of near-field mobility solutions for people with disabilities

vmax: 20 km/h, Range: 15-40 km, Idle weight: 48-55 kg


Segway i2 und Segway x2 (off-road )TU Ilmenau
